| Model | Configuration | Actuation | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Width (in) |
Width (mm) | Height (in) |
Height (mm) |
Air Inlet | Drive Size | Drive Type | Forward Torque (ft-lb) | Forward Torque (Nm) | Max Reverse Torque (ft-lb) | Max Reverse Torque (Nm) | Blows per minute | Free Speed (RPM) | Sound Level | Impacting Sound Level dB(A) — ISO15744 (pressure/power) | Free Speed Sound Level dB(A) — CAGI/ANSI S12.41 (pressure/power) | Vibration Level (m/s2) | Min Hose Size (in) |
Min Hose Size (mm) | Air Consumption @ Load (cfm) | Air Consumption @ Load (L/min) | Average Air Consumption (cfm) | Average Air Consumption (L/min) |
| 2850MAX | D-Handle | Inside Trigger | 19.43 | 8.8 | 13.1 | 334 | 4.4 | 112 | 7.9 | 200 | 1/2 in. NPTF | 1 in. | Square, Hog Ring | 2000 | 2715 | 2100 | 2850 | 770 | 5500 | Loud | 96.7/107.7 | 105.0/116.0 | 12.6 (3.6 uncertainty K) | 3/4 | 19 | 56 | 1587 | 14 | 397 |
| 2850MAX-6 | D-Handle | Inside Trigger | 21.58 | 9.8 | 19.1 | 486 | 4.4 | 112 | 7.9 | 200 | 1/2 in. NPTF | 1 in. | Square, Hog Ring | 2000 | 2715 | 2100 | 2850 | 770 | 5500 | Loud | 96.7/107.7 | 105.0/116.0 | 10.3 (1.9 uncertainty K) | 3/4 | 19 | 56 | 1587 | 14 | 397 |
| Model | Configuration | Actuation | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Width (in) |
Width (mm) | Height (in) |
Height (mm) |
Air Inlet | Drive Size | Drive Type | Forward Torque (ft-lb) | Forward Torque (Nm) | Max Reverse Torque (ft-lb) | Max Reverse Torque (Nm) | Blows per minute | Free Speed (RPM) | Sound Level | Impacting Sound Level dB(A) — ISO15744 (pressure/power) | Free Speed Sound Level dB(A) — CAGI/ANSI S12.41 (pressure/power) | Vibration Level (m/s2) | Min Hose Size (in) |
Min Hose Size (mm) | Air Consumption @ Load (cfm) | Air Consumption @ Load (L/min) | Average Air Consumption (cfm) | Average Air Consumption (L/min) |
| 2850MAX | D-Handle | Inside Trigger | 19.43 | 8.8 | 13.1 | 334 | 4.4 | 112 | 7.9 | 200 | 1/2 in. NPTF | 1 in. | Square, Hog Ring | 2000 | 2715 | 2100 | 2850 | 770 | 5500 | Loud | 96.7/107.7 | 105.0/116.0 | 12.6 (3.6 uncertainty K) | 3/4 | 19 | 56 | 1587 | 14 | 397 |
| 2850MAX-6 | D-Handle | Inside Trigger | 21.58 | 9.8 | 19.1 | 486 | 4.4 | 112 | 7.9 | 200 | 1/2 in. NPTF | 1 in. | Square, Hog Ring | 2000 | 2715 | 2100 | 2850 | 770 | 5500 | Loud | 96.7/107.7 | 105.0/116.0 | 10.3 (1.9 uncertainty K) | 3/4 | 19 | 56 | 1587 | 14 | 397 |
